Intel Core Series Fanless Home Office Mini PC With DDR3L Up To 8G And 8USB Ports
8USB Fanless Home Mini PC Description:
The X30 fanless home computer, powered by a 24-watt compact power supply (versus 160 watts for traditional desktops), cuts power consumption, saving costs and reducing carbon emissions. With up to 85% energy cost savings due to superior efficiency, it's a practical, affordable, and eco-friendly alternative to traditional desktops, providing similar capabilities.
It comes equipped with one VGA port that offers a resolution of 1920*1080 at a smooth 60Hz refresh rate. Additionally, there is one HDMI port capable of an impressive resolution of 3200*2000 also at 60Hz. This allows for flexible display options, whether you're connecting to older monitors via VGA or taking advantage of the higher resolution offered by HDMI. You can even use the synchronous or asynchronous display feature to customize your viewing experience according to your specific requirements.
This home office mini PC is perfect for a variety of tasks. Whether you're working on documents, browsing the web, streaming videos, or running light software applications, it provides the processing power you need. Its compact size makes it easy to fit on your desk without taking up too much space, while still delivering the performance of a full-sized PC.
8USB Fanless Home Mini PC Details:
| CPU | Intel Core i3 Series Processors: i3-4010Y: 2 Cores 4 Threads Processor, 1.30GHz Processor Base Frequency, 3 MB Cache, 11.5W TDP; i3-4005U: 2 Cores 4 Threads Processor, 1.70GHz Processor Base Frequency, 3 MB Cache, 15W TDP; i3-5005U: 2 Cores 4 Threads Processor, 2.0GHz Processor Base Frequency, 3 MB Cache, 15W TDP; Intel Core i5 Series Processors: i5-4200U: 2 Cores 4 Threads Processor, 1.6GHz Processor Base Frequency, 3 MB Cache, 15W TDP; i5-4200Y: 2 Cores 4 Threads Processor, 1.4GHz Processor Base Frequency, 3 MB Cache, 11.5W TDP; i5-5200U: 2 Cores 4 Threads Processor, 2.2GHz Processor Base Frequency, 3 MB Cache, 15W TDP; i5-5300U: 2 Cores 4 Threads Processor, 2.3GHz Processor Base Frequency, 3 MB Cache, 15W TDP; Intel Core i7 Series Processors: i7-4500Y: 2 Cores 4 Threads Processor, 1.8GHz Processor Base Frequency, 4 MB Cache, 15W TDP; i7-4500U: 2 Cores 4 Threads Processor, 1.8GHz Processor Base Frequency, 4 MB Cache, 15W TDP |
| GPU | Depends on CPU model |
| Memory | 1*DDR3L 1066MHz/1333MHz, Max Up To 8GB |
| Hard Disk | 1*mSATA SSD, 1*2.5 Inch HDD/ SSD (Data conversion rate SATA 2.0) |
| Expansion | 1*half-height Mini-PCIE Slot |
| Ethernet | 1*LAN 10/100/1000/ Mbps Realtek 8111F, Support Wake-on-LAN |
| Display | 1*VGA (1920*1080@60Hz), 1*HDMI (3200*2000@60Hz) Ports, Support synchronous or asynchronous display |
| Audio | Adopt Realtek ALC662 audio control chip, support dual-channel, stereo, Line out. |
| Operating System | Windows7, Windows8, Windows10, Ubuntu, Linux, CentOS, etc. |
| Power | 1*DC 12V 3A/36W (AC TO DC, 100 ~ 240V) |
| I/O Interface | 4*USB3.0, 4*USB2.0, 1*AUD In/Out, 1*LAN, 1*HDMI, 1*VGA, 1*DC, 1*Power Switch; Or 4*USB3.0, 2*USB2.0, 1*SPK, 1*MIC, 1*LAN, 1*HDMI, 1*VGA, 1*DC, 1*Power Switch |
| Material | Aluminum Housing |
| Mounting | VESA/ Wall Mount/ Desktop Mount |
| Size | 134*125*35MM |
| Weight | About 0.5KG |
| Color | Black |
| Suitable Temperature | Working temperature -20℃ ~ +65℃, Storage Temperature -20℃ ~ +75℃, Operating humidity 5% - 95% (relative humidity, no condensation) |
8USB Fanless Home Mini PC Processors:
For those seeking reliable and affordable performance, Intel Core i3 series processors like the i3-4010Y (2 cores, 4 threads, 1.30GHz base frequency, 3 MB cache, 11.5W TDP), i3-4005U (2 cores, 4 threads, 1.70GHz, 3 MB cache, 15W TDP), and i3-5005U (2 cores, 4 threads, 2.0GHz, 3 MB cache, 15W TDP) are excellent choices.
If you need more power for demanding tasks, consider Intel Core i5 series processors such as the i5-4200U (1.6GHz, 2 cores, 4 threads, 3 MB cache, 15W TDP), i5-4200Y (1.4GHz, 2 cores, 4 threads, 3 MB cache, 11.5W TDP), i5-5200U (2.2GHz, 2 cores, 4 threads, 3 MB cache, 15W TDP), and i5-5300U (2.3GHz, 2 cores, 4 threads, 3 MB cache, 15W TDP).
For top performance, Intel Core i7 series processors like the i7-4500Y and i7-4500U (both 2 cores, 4 threads, 1.8GHz, 4 MB cache, 15W TDP) are ideal.
8USB Fanless Home Mini PC Hard Disk And Memory:
With 1*DDR3L memory that supports frequencies of 1066MHz/1333MHz, with the ability to max up to 8GB. This allows for smooth multitasking and efficient running of various applications. It also features 1*mSATA SSD and 1*2.5 Inch HDD/SSD (with a data conversion rate of SATA 2.0 for the hard disk), providing ample storage space for your files, documents, and media.
8USB Fanless Home Mini PC Interfaces:
The home office computer is equipped with a 10/100/1000 Mbps LAN port powered by Realtek 8111F, ensuring seamless and stable network access. It also has a single Mini PCIe 300M WiFi slot for strong signals and super-fast, stable internet. Additionally, it supports Wake-on-LAN for convenient remote wake-up from sleep or standby mode.
8USB Fanless Home Mini PC Cooling Method:
One of its standout qualities is the incorporation of a fanless cooling system. This is highly impressive as it guarantees that high performance is maintained continuously, 24/7. Without the noise and potential distractions of a fan, it offers a serene working environment. The fanless design not only ensures quiet performance but also enhances reliability by reducing the risk of mechanical failures associated with traditional cooling fans.
