Intel Celeron J6412 4 Core 4 Thread Mini PC With Dual LAN Dual COM For Industrial
Intel Mini PC Decription:
The Mini PC is powered by Intel Celeron J6412 quad-core, octa-threaded processor with a core frequency of up to 2.6GHz, a significant improvement over the previous generation core to give you a fast experience.
As a fanless industrial PC is noiseless and resistant to dust, debris and corrosion, reducing maintenance costs and minimizing downtime.
In addition, with the rich interfaces of 2*RJ45 LAN, 2*COM RS232/RS485, 1* HDMI, 1*VGA, 4*USB 3.0 and 2*USB 2.0, there is an easy interconnection between devices.
It can be used for online classes live, auto optical inspection, machinery automation, ePolice infotainment, surveillance or image processing equipment and healthcare industry. The Industrial Mini PC is absolutely a good choice to be your office assistant and home entertainment tool.
Intel Mini PC Details:
Intel Mini PC Details | External I/O Ports | 1x Power Button; 1x 3.5mm Audio Jack, support MIC in, Line out; 1x 4Pins power input connector; 4x USB3.0; 2x USB2.0; 2x COM DB9 ( support RS232/RS485 adjustable ); 2x RJ45 Realtek 8111H GbE LAN; 1x HDMI; 1x VGA |
| Internal I/O Ports | 1x SODIMM DDR4 ; 1x M.2 PCIE/SATA SSD; 1x SATA3.0 2.5 inch; 1x mini PCIe for WiFi, 3G/4G Module |
| OS Support | Windows 10, Windows 11, LINUX, Ubuntu, etc. |
| BIOS | 128Mb Flash ROM |
| Watchdog | Support hardware reset function (256 levels, 0~255 seconds) |
| Dual Display | 1*HDMI and 1*VGA 4K@ 60Hz, support for Dual-line Synchronous or Independent display |
| Other | Wake up on LAN, S5 RTC Wake Settings, PXE Boot, Restore AC power loss(Auto Power On) |
| Power | 1*DC, 12V |
| Dimension/Weight | 136mm*126mm*40mm / 0.65KG |
| Material/Color | Aluminum / Black |
| Suitable Temperatur | Operating Temperature: -10℃ to +60℃, Storage Temperature: -20℃ to +70℃, Storage Humidity: 5%~95% (relative humidity, no condensation) |
Intel Mini PC Celeron J6412 Processor:
The Industrial Mini PC is powered by Intel Celeron J6412 quad-core, four-thread processor with a core frequency of up to 2.6GHz, a significant improvement over the previous generation core to give you a fast experience.
Intel Mini PC Memory And Hard Disk:
The industrial mini PC supports DDR4 memory up to 16GB, which is faster and more energy efficient than DDR3, providing superior performance for mini PC.
Intel J6412 fanless industrial PC supports an M.2 Key-M PICE or SATA SSD, and a 2.5-inch hard drive, giving you the ability to create your own hard drive that meets your needs.
Intel Mini PC Product Interfaces:
